D-Link DNS-320L User Manual

299D-Link ShareCenter DNS-320L User Manual
Section 4 - Conguration
Click or click and drag your mouse over the time frame you want to delete. The
selected frames will return to light blue to indicate no recording schedule. You
can also check Select All to select all frames.
Click Save Settings to nish

D-Link DNS-320L Specifications

Power

power supply	External DC 12 V / 3 A
power saving mode	Auto power recovery
scheduled power off	Supported

Operating Environment

operating temperature	32 to 104 ˚F (0 to 40 ˚C)
storage temperature	-4 to 158 ˚F (-20 to 70 ˚C)
humidity	5% to 90% non-condensing

Ports & Interfaces

ethernet port	1 x 10/100/1000 Gigabit
usb port	1 x USB 2.0
connection to UPS	Supported through USB port

Weight and Dimensions

weight	0.25 lbs
dimensions	3.54” x 5.68” x 7.6”
dimensions (mm)	90 x 144.3 x 193.3 mm
