D-Link DXS-1210 Series User Manual

4 Configuration D-Link DXS-1210 Series User Manual
5
5
9
9
Click the Clear button to remove the specified port of LLDP neighbor port or click Clear All button to remove
all LLDP neighbor ports.
L3 Features > ARP > ARP Aging Time
The ARP Aging Time page allows you to view and configure the ARP aging time settings.
Figure 4.98 – L3 Features > ARP > ARP Aging Time
Timeout(min): Specifies the aging time of the ARP entry. The default is 5 minutes.
Click the Apply button to save your settings.
Click the Edit button to re-configure the specific entry.
Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.
L3 Features > ARP > Static ARP
The Static ARP page provides information regarding each interface, including which IP address was mapped
to what MAC address. Enter an IP Address or Hardware Address and then click Apply to create a new
ARP entry.
Figure 4.99 – L3 Features > ARP > Static ARP
Click Edit to modify the Hardware Address.
Click Delete to remove the information from ARP table.
Click Delete All to remove all information from ARP table.
Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.
L3 Features > ARP > ARP Table
The ARP Table page allows you to view and configure the ARP table settings.

D-Link DXS-1210 Series Specifications

General

Product Series	DXS-1210
Power Supply	Internal
Jumbo Frame Support	9KB
Number of Ports	12
Layer	L2+
Form Factor	Rack-mountable
Uplink Ports	10G SFP+
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
