xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide
128
config port_vlan
Purpose
Used to set the ingress checking status, and the sending and receiving GVRP information.
Syntax config port_vlan [<portlist> | all] { gvrp_state [enable | disable] | ingress_checking
[enable | disable] | acceptable_frame[tagged_only | admit_all]pvid<vlanid 1-4094>}(1)
Description
This command is used to configure the Group VLAN Registration Protocol on the Switch.
Ingress checking, the sending and receiving of GVRP information, and the Port VLAN ID
(PVID) can be configured.
Parameters
<portlist> − A port or range of ports for which users want to enable GVRP for.
all − Specifies all of the ports on the Switch.
gvrp_state [enable | disable] − Enables or disables GVRP for the ports specified in the port
list.
ingress_checking [enable | disable] − Enables or disables ingress checking for the specified
port list.
acceptable_frame [tagged_only | admit_all] – This parameter states the frame type that will
be accepted by the Switch for this function. tagged_only implies that only VLAN tagged
frames will be accepted, while admit_all implies tagged and untagged frames will be
accepted by the Switch.
pvid <vlanid 1-4094> – Specifies the default VLAN associated with the port.
Restrictions
Only Administrator and Operator users can issue this command.
Example usage:
To set the ingress checking status, the sending and receiving GVRP information:
enable gvrp
Purpose
Used to enable the GARP VLAN Registration Protocol (GVRP).
Syntax enable gvrp
Description This command, along with disable gvrp below, is used to enable and disable GVRP on the
Switch, without changing the GVRP configuration on the Switch.
Parameters
None.
Restrictions
Only Administrator and Operator and Power-User-level users can issue this command.
Example usage:
To enable the GARP VLAN Registration Protocol (GVRP):
