xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide
127
config vlan vlanid
Purpose
Used to add additional ports to a previously configured VLAN and enable or disable the
VLAN advertisement.
Syntax config vlan vlanid <vidlist> {[ add [ tagged | untagged | forbidden ] | delete ] <portlist> |
advertisement [ enable | disable ] | name <vlan_name 32>}(1)
Description
This command allows you to add or delete ports of the port list of previously configured
VLAN(s). You can specify the additional ports as being tagged, untagged or forbidden. The
same port is allowed to be a tagged, untagged or forbidden member port of multiple VLAN’s.
You can also specify if the VLAN will join GVRP or not with the advertisement parameter.
The name parameter allows you to specify the name of the VLAN that needs to be modified.
Parameters
<vidlist> − Specifies a range of multiple VLAN IDs to be configured.
tagged − Specifies the additional ports as tagged.
untagged − Specifies the additional ports as untagged.
forbidden − Specifies the additional ports as forbidden.
<portlist> − A range of ports to add to or delete from the VLAN.
advertisement − Entering the advertisement parameter specifies if the VLAN should join
GVRP or not. There are two parameters:
 enable − Specifies that the VLAN should join GVRP.
 Disable − Specifies that the VLAN should not join GVRP.
name − Entering the name parameter specifies the name of the VLAN to be modified.
<vlan_name 32> − Enter a name for the VLAN.
Restrictions
Only Administrator and Operator and Power-User-level users can issue this command.
Example usage:
To config vlan vlanid on the Switch:
