xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide
153
config link_aggregation algorithm
Purpose
Used to configure the link aggregation algorithm.
Syntax config link_aggregation algorithm [mac_source | mac_destination | mac_source_dest |
ip_source | ip_destination | ip_source_dest] }
Description
This command configures the part of the packet examined by the Switch when selecting the
egress port for transmitting load-sharing data. This feature is only available using the
address-based load-sharing algorithm.
Parameters
mac_source − Indicates that the Switch should examine the MAC source address.
mac_destination − Indicates that the Switch should examine the MAC destination address.
mac_source_dest − Indicates that the Switch should examine the MAC source and
destination addresses
ip_source − Indicates that the Switch should examine the IP source address.
ip_destination − Indicates that the Switch should examine the IP destination address.
ip_source_dest − Indicates that the Switch should examine the IP source address and the
destination address.
Restrictions
Only Administrator and Operator and Power-User-level users can issue this command.
Example usage:
To configure link aggregation algorithm for mac-source-dest:
show link_aggregation
Purpose
Used to display the current link aggregation configuration on the Switch.
Syntax show link_aggregation {group_id <value 1-8> | algorithm}
Description
This command will display the current link aggregation configuration of the Switch.
Parameters
<value 1-8> − Specifies the group ID. The Switch allows up to 8 link aggregation groups to
be configured. The group number identifies each of the groups.
algorithm − Allows users to specify the display of link aggregation by the algorithm in use by
that group.
Restrictions
None.
Example usage:
To display Link Aggregation configuration:
