show lldp
Purpose
Used to display the Switch’s general LLDP configuration status.
Syntax show lldp
Description
This command displays the Switch’s general LLDP configuration status.
Parameters
None.
Restrictions
None.
Usage Example:
To display the LLDP system level configuration status:
DES-3528:admin# show lldp
Command: show lldp
LLDP System Information
Chassis ID Subtype : MAC Address
Chassis ID : 00-80-C2-11-22-00
System Name :
System Description : Fast Ethernet Switch
System Capabilities : Repeater, Bridge
LLDP Configurations
LLDP Status : Disabled
LLDP Forward Status : Disabled
Message Tx Interval : 30
Message Tx Hold Multiplier: 4
ReInit Delay : 2
Tx Delay : 2
Notification Interval : 5
DES-3528:admin#
show lldp mgt_addr
Purpose
Used to display the LLDP management address information.
Syntax show lldp mgt_addr {[ipv4 {<ipaddr>} | ipv6 {<ipv6addr>}]}
Description
This command displays the LLDP management address information.
Parameters ipv4 - (Optional) Specify the IPv4 address used for the display.
<ipaddr> - (Optional) Enter the IPv4 address used for this configuration here.
ipv6 - (Optional) Specify the IPv6 address used for the display.
<ipv6addr> - (Optional) Enter the IPv6 address used for this configuration here.
Restrictions
None.
Example usage:
To display management address information:
DES-3528:admin#show lldp mgt_addr ipv4 10.90.90.90
Command: show lldp mgt_addr ipv4 10.90.90.90
Address 1 :
------------------------------------------------
Subtype : IPv4
Address : 10.90.90.90
IF Type : IfIndex
OID : 1.3.6.1.4.1.171.10.105.1
Advertising Ports :
DES-3528:admin#
