xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide
538
DES-3528:admin# config erps raps_vlan 4094 ring_port west 5
Command: config erps raps_vlan 4094 ring_port west 5
Success.
DES-3528:admin#
config erps raps_vlan rpl_port
Purpose
This command is used to configure the RPL port.
Syntax config erps raps_vlan <vlanid> rpl_port [west | east | none]
Description RPL port - Specifies one of the R-APS VLAN ring ports as the RPL port. To remove an RPL
port from an R-APS VLAN, use the none designation for rpl_port.
Note that the RPL port cannot be modified when ERPS is enabled; and the virtual channel
cannot be configured as RPL. For example, if a ring port is configured on the virtual channel
and the ring port is configured as an RPL port, an error message will be display and the
configuration will fail
Parameters raps_vlan - Specifies the R-APS VLAN used.
<vlanid> - Enter the VLAN ID used here.
rpl_port - Specifies the RPL port used.
west - Specifies the west ring port as the RPL port.
east - Specifies the east ring port as the RPL port.
none - No RPL port on this node. By default, the node has no RPL port.
Restrictions
Only Administrator, Operator and Power User-level users can issue this command.
Example usage:
To configure the RPL port for a specific R-APS VLAN:
DES-3528:admin# config erps raps_vlan 4094 rpl_port west
Command: config erps raps_vlan 4094 rpl_port west
Success.
DES-3528:admin#
config erps raps_vlan rpl_owner
Purpose
This command is used to configure the RPL owner.
Syntax config erps raps_vlan <vlanid> rpl_owner [enable | disable]
Description RPL owner - Specifies the node as the RPL owner.
Note that the RPL owner cannot be modified when ERPS is enabled; and the virtual channel
cannot be configured as RPL. For example, if a ring port is configured on the virtual channel
and the ring port is configured as an RPL port, an error message will be display and the
configuration will fail
Parameters raps_vlan - Specifies the R-APS VLAN used.
<vlanid> - Enter the VLAN ID used here.
rpl_owner - Specifies to enable or disable the RPL owner node.
enable - Specifies the device as an RPL owner node.
disable - This node is not an RPL owner. By default, the RPS owner is disabled.
Restrictions
Only Administrator, Operator and Power User-level users can issue this command.
Example usage:
To configure the RPL owner for a specific R-APS VLAN:
