The wire gauge of the power cable should be sufficient to accommodate a surge during power-up of
at least 5 amps with a minimum voltage drop between the power supply and module sections. The
module has a single +24 Volt supply per section. If there is a voltage drop between the power
supply and module, ensure that the power supply voltage is at least 24 Volts plus this voltage drop.
The module input supply voltage can be read using CamExpert. The module will not power up
below approximately 20V.
