Linea HS Series Camera User's Manual AxCIS Series Camera Features • 9

Part Numbers and Software Requirements

The camera is available in the following configurations:

Note: The prototypes are always shipped with LED arrays where the user can readily remove them

if required. However, the Standard AxCIS cameras require lighting to be ordered separately.

Table 1: Camera Models Comparison

Part Number

Resolution

Field of View

Max. Line Rates

Pixel Size

Control & Data

Monochrome

CS-FM-04L12A-00

AX-FM-04A12H-00

600dpi

400mm

120kHz single

mono /60 kHz Dual

Exposure mono

42x42um

Camera Link HS

LC fiber optic

CS-FM-08L12A-00

AX-FM-08A12H-00

600dpi

800mm

120kHz single

mono /60 kHz Dual

Exposure mono

42x42um

Camera Link HS

LC fiber optic

CS-FM-08L12B-00

AX-FM-08B12H-00

900 dpi

800mm

120kHz single

mono /60 kHz Dual

Exposure mono

28x28 µm

Camera Link HS

LC fiber optic

Table of Contents2
Figures5
Axcis Series Camera Features5
CIS Optical Technology6
Camera Highlights8
Common Features8
Resolution8
Programmable Features8
Applications8
Part Numbers and Software Requirements9
Cs-Fm-04L12A-009
Ax-Fm-04A12H-009
Cs-Fm-08L12A-009
Ax-Fm-08A12H-009
Cs-Fm-08L12B-009
Ax-Fm-08B12H-009
Supported Industry Communications Standards10
Genicam10
Image Data Cables and Transceivers11
Figure 1: Linea CLHS Dual LC/SFP+ Connector Configuration11
Figure 2: Single CLHS Connector Configuration11
Mechanical Drawings13
Figure 3: CS-FM-04L12A-00 Prototype Mechanical Drawing13
Figure 4: CS-FM-08L12A/B-50 Prototype Mechanical Drawing13
Precautions14
Electrostatic Discharge and the CMOS Sensors14
Install & Configure Frame Grabber & Software15
Using Sapera Camexpert15
Camexpert Panes16
Figure 5: Camexpert Frame Grabber Control Window16
Setting up for Imaging18
Camera I / O Connectors18
Powering the Module18
Figure 6. Module I / O Connectors18
Power and GPIO Connections20
Figure 7: 26-Pin High Density D-Sub Pin Numbering20
Establishing Module Communications22
Selecting the Data Format22
Establishing Data Integrity23
Camera Features24
Synchronizing to Object Motion24
Acquiring Images: Triggering the Camera24
Measuring Line (Trigger) Rate25
Maximum Line Rate25
Minimum Line Rate25
Scan Direction25
Figure 8. Image with Correct Scan Direction26
Figure 9. Image with Incorrect Scan Direction26
Camera Orientation27
Automatic Sensor Alignment27
Figure 10: Example of Object Movement and Module Direction27
Maintaining Image Alignment28
Dual Exposure Mode (HDR)29
Internal Trigger Mode30
Establishing the Optimal Response31
Image Response Uniformity & Flat Field Calibration31
Saving & Loading a PRNU Set Only33
Flat Field Calibration Regions of Interest33
Binning34
Figure 11: 2X2 Binning34
Using Area of Interest (Aois)35
Steps to Setup Area of Interest for each Section36
Rules for Setting Areas of Interest36
Adjusting Responsivity and Contrast Enhancement37
Black Level37
Figure 12: Black Level, Row Gain and System Gain Processing Chain37
Changing Output Configuration38
Pixel Format38
Establishing the Desired Object Pixel Size38
Encoder Multiplier38
Ensuring Image Alignment & Response Level39
Object Pixel Size39
Angle Correction39
Response Leveling39
Optional Led Array Control40
Saving & Restoring Camera Setup Configurations41
Figure 13. Relationship between Camera Settings41
Active Settings for Current Operation42
User Setting42
Factory Settings42
Default Setting42
Appendix A: Genicam Commands43
Camera Information Category44
Camera Information Feature Descriptions44
Figure 14 Example Camexpert Module Information Panel44
Built-In Self-Test Codes (BIST)47
Camera Power-Up Configuration Selection Dialog47
Camera Power-Up Configuration47
Figure 15: Camexpert Power-Up Configuration Dialog47
User Set Configuration Management48
Camera Control Category49
Camera Control Feature Descriptions49
Figure 16: Module Control Panel49
Digital Io Control Category52
Digital IO Control Feature Descriptions52
Figure 17 Digital I/O Control Panel52
Flat Field Category54
Flat Field Control Feature Description54
Figure 18: Flat Field Panel54
Image Format Control Category56
Image Format Control Feature Description56
Figure 19: Image Format Panel56
File Access Control Category58
File Access Control Feature Descriptions58
Figure 20: File Access Control Panel58
File Access Via the Camexpert Tool60
Figure 21: File Access Control Tool60
Figure 22: File Upload Completed Message Box60
CLHS File Transfer Protocol61
Upload File to Camera62
Download a List of Camera Parameters62
Transport Layer Control Category63
Transport Layer Feature Descriptions63
Figure 23: Transport Layer Panel63
Acquisition and Transfer Control Category65
Acquisition and Transfer Control Feature Descriptions65
Figure 24: Acquisition & Transfer Control Panel65
Appendix B: Trouble Shooting Guide66
Diagnostic Tools66
Figure 25: Camexpert Voltage & Temperature Features66
Figure 26: Camexpert Test Pattern Feature67
Resolving Camera Issues69
Communications69
Image Quality Issues70
Power Supply Issues73
Declarations of Conformity73
Document Revision History74
