Linea HS Series Camera User's Manual Contents • 5
Figures
Figure 1: Linea CLHS Dual LC/SFP+ Connector Configuration 11
Figure 2: Single CLHS Connector Configuration 11
Figure 3: CS-FM-04L12A-00 Prototype Mechanical Drawing 13
Figure 4: CS-FM-08L12A/B-50 Prototype Mechanical Drawing 13
Figure 5: CamExpert Frame Grabber Control Window 16
Figure 6. Module I / O Connectors 18
Figure 7: 26-pin high density D-Sub Pin Numbering 20
Figure 8. Image with correct scan direction 26
Figure 9. Image with incorrect scan direction 26
Figure 10: Example of Object Movement and Module Direction 27
Figure 11: 2x2 Binning 34
Figure 12: Black Level, Row Gain and System Gain Processing Chain 37
Figure 13. Relationship Between Camera Settings 41
Figure 14 Example CamExpert Module Information Panel 44
Figure 15: CamExpert Power-Up Configuration Dialog 47
Figure 16: Module Control Panel 49
Figure 17 Digital I/O Control Panel 52
Figure 18: Flat Field Panel 54
Figure 19: Image Format Panel 56
Figure 20: File Access Control Panel 58
Figure 21: File Access Control Tool 60
Figure 22: File Upload Completed Message Box 60
Figure 23: Transport Layer Panel 63
Figure 24: Acquisition & Transfer Control Panel 65
Figure 25: CamExpert Voltage & Temperature Features 66
Figure 26: CamExpert Test Pattern Feature 67
AxCIS Series Camera Features
Description
This user manual is preliminary.
This document details the camera features. Please contact the factory for performance
specifications or any other technical details.
Teledyne DALSA introduces a breakthrough CMOS line scan CIS format module with unprecedented
speed, responsivity and low noise.
Over time, Teledyne DALSA will release the complete range of CIS modules from less than 300mm
to 1500mm. The name of this product family is AxCIS. Initial offering has 400 and 800mm scan
widths at 600dpi or 900dpi resolution with optional integrated white LED illumination
