Linea HS Series Camera User's Manual AxCIS Series Camera Features • 23
Establishing Data Integrity
• Use the module’s internal triggering. This allows for initial imaging with a static object and
no encoder input is required.
• Enable the module to output a test pattern.
• Use a frame grabber CamExpert instance to capture, display and analyze the test pattern
image to verify the integrity of the connection. If the test pattern is not correct, check the
cable connections and the frame grabber setup.
• Disable the test pattern output.
