6 • AxCIS Series Camera Features Linea HS Series Camera User's Manual
The AxCIS incorporates Teledyne DALSA’s latest CMOS sensor technology in a staggered
arrangement that ensures 100% image coverage without interpolation and self-calibration
capabilities to ensure image uniformity and alignment.
These cameras have a maximum line rate of 120 kHz with up to 900dpi resolution for any length of
module.
The camera uses the Camera Link HS™ interface—the industry standard for a very high-speed fiber
optic camera interface with long transmission distances and cable flexing requirements
Teledyne DALSA’s AxCIS modules and compatible frame grabbers combine to offer a complete
solution for the next generation of automatic optical inspection systems.
These modules are recommended when there is restricted space available to locate the imaging
system. Teledyne DALSA’s AxCIS modules are well suited for detecting defects at high speeds over
a large fields of view where the ‘telocentric like’ properties of the Selfoc Lens Array (SLA) are
desirable for limited measurement purposes and consistent defect classification.
Preliminary Monochrome Models
400mm field of view, 600dpi, maximum line rate of 120 kHz,
monochrome output, Camera Link HS LC fiber optic connectors. Note:
Prototype includes integrated lighting, however, AxCIS requires 2 of AC-
LE-10008-00 for integrated lighting.
400mm field of view, 900dpi, maximum line rate of 120 kHz,
monochrome output, Camera Link HS LC fiber optic connectors. Note:
Prototype includes integrated lighting, however, AxCIS requires 2 of AC-
LE-10008-00 for integrated lighting.
800mm field of view, 600dpi, maximum line rate of 120 kHz,
monochrome output, Camera Link HS LC fiber optic connectors. Note:
Prototype includes integrated lighting, however, AxCIS requires 2 of AC-
LE-10008-00 for integrated lighting.
800mm field of view, 900dpi, maximum line rate of 120 kHz,
monochrome output, Camera Link HS LC fiber optic connectors. Note:
Prototype includes integrated lighting, however, AxCIS requires 2 of AC-
LE-10008-00 for integrated lighting.
CIS Optical Technology
AxCIS combines a Selfoc Lens Array (SLA), an linear array of TeledyneDALSA CMOS sensors,
Image processing, power management and optional integrated LED illumination to provide a
complete imaging solution. Industry refers to this configuration as Contact Image Sensor (CIS)
technology.
What make CIS unique is the SLA which is an optical device consisting of an array of Gradient
Index Lenses (GRIN’s) that used at a magnification of 1x, reproducing the object at the sensors
image plane in a line of the over long lengths with a short working distance. This allows for a very
compact imaging module that can be in confined spaces.
