Linea HS Series Camera User's Manual Appendix A: GenICam Commands • 53
Display Name
Feature
Description
View
Rotary Encoder Direction
rotaryEncoderDirection
Specifies the phase which defines the encoder
forward direction.
Beginner
DFNC
Counter Clockwise
CounterClockwise
Inspection goes forward when the rotary encoder
direction is counter clockwise (phase A is ahead of
phase B).
Clockwise
Clockwise
Inspection goes forward when the rotary encoder
direction is clockwise (phase B is ahead of phase A).
Rotary Encoder Output
Mode
rotaryEncoderOutputMode
Specifies the conditions for the Rotary Encoder
interface to generate a valid Encoder output signal.
Beginner
DFNC
Position
Position
Triggers are generated at all new position
increments in the selected direction. If the encoder
reverses no trigger events are generated until it has
again passed the position where the reversal started.
Motion
Motion
The triggers are generated for all motion increments
in either direction.
Input Line Debouncing
Period
lineDebouncingPeriod
Specifies the minimum delay before an input line
voltage transition is recognizing as a signal
transition.
Beginner
DFNC
Rotary Encoder Multiplier
rotaryEncoderMultiplier
Specifies a multiplication factor for the rotary
encoder output pulse generator.
Beginner
DFNC
Rotary Encoder Rescaler
Order
rotaryEncoderRescalerOrder
Specifies the order that the multiplier and divider are
applied.
Guru
DFNC
Multiplier Divider
multiplierDivider
The signal is multiplied before been divided.
Divider Multiplier
dividerMultiplier
The signal is divided before been multiplied
LED Selector
ledSelector
Both
LED1
LED2
Specified which LED array intensity is adjusted
Both LED’s are adjusted to the desired intensity
LED1 is adjusted to the desired intensity
LED2 is adjusted to the desired intensity
Beginner
DFNC
LED Intensity
ledIntensity
Specified the selected LED intensity
Beginner
DFNC
