64 • Appendix A: GenICam Commands Linea HS Series Camera User's Manual

CLHS 64b/66b

Receive Error Count

Selector

clhsErrorCountSelector

Select the error to count

Guru

DFNC

Cable A Corrupted

Packet Count

CorruptedPacketCntA

Count of corrupted packets on cable A.

Cable A Corrected

Packet Count

CorrectedPacketCntA

Count of corrected packets on cable A.

Cable B Corrupted

Packet Count

CorruptedPacketCntB

Count of corrupted packets on cable B.

Cable B Corrected

Packet Count

CorrectedPacketCntB

Count of corrected packets on cable B.

CLHS 64b/6b

Receive Error Count

clhsErrorCount

CLHS 64b/66b Receive Error Count

Guru

DFNC

Refresh CLHS

64b/66b Receive

Error Count

clhsErrorCountRefresh

Refresh the selected clhsErrorCount value.

Guru

DFNC

Reset Receive Error

Count

clhsErrorCountReset

Reset the selected clhsErrorCount value to 0.

Guru

DFNC
