Xtium2-CLHS PX8 User's Manual CamExpert Quick Start • 33
Line Trigger
Method Setting
CORACQ_PRM_LINE_TRIGGER_METHOD
Sets the method for line trigger pulse
output.
Applies to linescan
cameras only
Camera Frames
Per Trigger
CORACQ_PRM_CAM_FRAMES_PER_TRIGGER
Specifies the number of frames output by
the camera per trigger; currently not
available.
Applies to area
scan cameras
only.
Camera Control
During Readout
CORACQ_PRM_CAM_CONTROL_DURING_READOUT Specifies if the camera control signals can
be sent during the readout of a frame.
Possible values are:
• Valid
• Invalid
Strobe Method
Setting
CORACQ_PRM_STROBE_METHOD
CORACQ_PRM_STROBE_ENABLE
CORACQ_PRM_STROBE_DELAY
CORACQ_PRM_STROBE_DURATION
CORACQ_PRM_STROBE_LEVEL
CORACQ_PRM_STROBE_POLARITY
When a strobe output signal from the
acquisition board is required, select and
configure the control method required.
Note, method 1 is only available for
areascan camera type; method 3 for line
scan only.
Line Trigger Auto
Delay
CORACQ_PRM_LINE_TRIGGER_AUTO_DELAY
Enables delaying line triggers to a camera
based on the selected method. Used to
avoid over-triggering a camera.
Applies to linescan
cameras only
Time Stamp Base CORACQ_PRM_TIME_STAMP_BASE Sets the counter stamp time base. Possible
values are:
• Microseconds
• Line Counts
• External line trigger or shaft
encoder
• Shaft Encoder
Board Sync
Output 1 Source
CORACQ_PRM_BOARD_SYNC_OUTPUT1_SOURCE Specifies the signal to output on board sync
output 1. This parameter permits the
synchronization of two acquisition devices
using a signal from one acquisition device
and synching the second acquisition device
with it.
Board Sync
Output 2 Source
CORACQ_PRM_BOARD_SYNC_OUTPUT2_SOURCE
Specifies the signal to output on board sync
output 2. This parameter permits the
synchronization of two acquisition devices
using a signal from one acquisition device
and synching the second acquisition device
with it.
