Danfoss VLT AutomationDrive FC 302

Option
Function
[128]
Dir. home sen.
inv.
N O T I C E
This option is only available with software version 48.XX.
Normally closed contact for defining the home position at the same edge of the sensor signal inde-
pendent of running direction. Only for the 2 homing types [2] Home Sync and [9] Direction with Sensor.
[190]
Emcy mode ref
bit 0
Enables a choice between 1 of the 8 preset reference according to Table 329.
[191]
Emcy mode ref
bit 1
Enables a choice between 1 of the 8 preset reference according to Table 329.
[192]
Emcy mode ref
bit 2
Enables a choice between 1 of the 8 preset reference according to Table 329.
[193]
Emcy mode
setup bit 0
Switch between emergency mode setup 1 to 4 in parameter group 24-0* Emergency Mode and parame-
ter group 24-4* Emergency Mode 2 without changing starting setup mode for the rest of the parameters.
[194]
Emcy mode
setup bit 1
Switch between emergency mode setup 1 to 4 in parameter group 24-0* Emergency Mode and parame-
ter group 24-4* Emergency Mode 2 without changing starting setup mode for the rest of the parameters.
[195]
Test emcy
mode
Activation of emergency mode via parameter 24-09 Emergency Mode Alarm Handling, option [2] Trip all
alarms/test with stop on all alarms and in normal operation mode. The test timer is set in parameter
24-42 Timeout for Emergency Mode Test, and countdown starts when the test signal is active.
[196]
Reset emcy
mode
When operating in emergency mode with impulse signals (parameter 24-43 Emergency Mode Signal Op-
eration, option [2] Impulse, set-reset) the reset signal stops the emergency mode operation.
[231]
Power limit
mot.
N O T I C E
This option is only available in FC 302.
Serves as input to activate the power limit function in the motor mode. See parameter group 4-8* Power
Limit.
[232]
Power limit
gen.
N O T I C E
This option is only available in FC 302.
Serves as input to activate the power limit function in the generating mode. See parameter group 4-8*
Power Limit.
[233]
Power limit
both
N O T I C E
This option is only available in FC 302.
Serves as input to activate the power limit function in both the motor and the generating mode. See
parameter group 4-8* Power Limit.
[234]
Light load +
evacuation
N O T I C E
This option is only available in FC 302.
Use this option to activate both light-load detection and evacuation.
