Danfoss VLT AutomationDrive FC 302

Parameter 5-10 Terminal 18 Digital Input
Table 335: Parameter 5-10 Terminal 18 Digital Input
5-10 Terminal 18 Digital Input
Default value: Size related
Parameter type: Option
Setup: All setups
Conversion index: –
Data type: Uint8
Change during operation: True
Select the function from the available digital input range and the additional options [60] Counter A (up), [61] Counter A (down), [63]
Counter B (up), and [64] Counter B (down). Counters are used in smart logic control functions. All functions are described in
Table 328,
Table 330, Table 332, and Table 334.
Option
Name
Description
[0]
No operation
[1]
Reset
[2]
Coast inverse
[3]
Coast and reset inv
[4]
Quick stop inverse
[5]
DC-brake inverse
[6]
Stop inverse
[8]
Start
[9]
Latched
[10]
Reversing
[11]
Start reversing
[12]
Enable start forward
[13]
Enable start reverse
[14]
Jog
[15]
Preset reference on
[16]
Preset ref bit 0
[17]
Preset ref bit 1
[18]
Preset ref bit 2
[19]
Freeze reference
[20]
Freeze output
[21]
Speed up
[22]
Speed down
[23]
Set-up select bit 0
[24]
Set-up select bit 1
[26]
Precise stop inverse
[27]
Precise start, stop
AU275636650261en-000101 / 130R0334 | 189Danfoss A/S © 2022.12
Parameter Descriptions
VLT AutomationDrive FC 301/302
Programming Guide
