Illustration 8.45 Rectifier Cabinet, frame size F10 and F12
1)
12-pulse rectifier module 4) Line
2) AUX Fan R1 S1 T1 R2 S2 T2
100 101 102 103 L1-1 L2-1 L3-1 L1-2 L2-2 L3-2
L1 L2 L1 L2 5) DC Bus Connections for common DC Bus
3) Line Fuses F10/F12 (6 Pieces) DC+ DC-
6) DC Bus Connections for common DC Bus
DC+ DC-
Electrical Installation FC 300 Design Guide
184 MG.33.BD.02 - VLT
®
