Danfoss VLT AutomationDrive Design Guide

Mains Supply 3 x 525- 690V AC
FC 302 P110 P132 P160 P200
High/ Normal Load* HO NO HO NO HO NO HO NO
Typical Shaft output at 550V
[kW]
90 110 110 132 132 160 160 200
Typical Shaft output at 575V
[HP]
125 150 150 200 200 250 250 300
Typical Shaft output at 690V
[kW]
110 132 132 160 160 200 200 250
Enclosure IP21 D1 D1 D2 D2
Enclosure IP54 D1 D1 D2 D2
Enclosure IP00 D3 D3 D4 D4
Output current
Continuous
(at 550V) [A]
137 162 162 201 201 253 253 303
Intermittent (60 sec
overload)
(at 550V) [A]
206 178 243 221 302 278 380 333
Continuous
(at 575/690V) [A]
131 155 155 192 192 242 242 290
Intermittent (60 sec
overload)
(at 575/690V) [A]
197 171 233 211 288 266 363 319
Continuous KVA
(at 550V) [KVA]
131 154 154 191 191 241 241 289
Continuous KVA
(at 575V) [KVA]
130 154 154 191 191 241 241 289
Continuous KVA
(at 690V) [KVA]
157 185 185 229 229 289 289 347
Max. input current
Continuous
(at 550V) [A]
130 158 158 198 198 245 245 299
Continuous
(at 575V) [A]
124 151 151 189 189 234 234 286
Continuous
(at 690V) [A]
128 155 155 197 197 240 240 296
Max. cable size, mains
motor, load share and brake
[mm
2
(AWG)]
2 x 70 (2 x 2/0) 2 x 70 (2 x 2/0)
2 x 150 (2 x 300
mcm)
2 x 150 (2 x 300
mcm)
Max. external mains fuses
[A]
1
315 350 350 400
Estimated power loss
at 600V [W]
4)
1890 2230 2101 2617 2491 3197 3063 3757
Estimated power loss
at 690V [W]
4)
1953 2303 2185 2707 2606 3320 3192 3899
Weight,
Enclosure IP21, IP54 [kg]
96 104 125 136
Weight,
Enclosure IP00 [kg]
82 91 112 123
Efficiency
4)
0.98
Output frequency 0 - 600 Hz
Heatsink overtemp. trip
90°C 110°C 110°C 110°C
Power card ambient trip
75°C
* High overload = 160% torque during 60 sec., Normal overload = 110% torque during 60 sec.
FC 300 Selection FC 300 Design Guide
MG.33.BD.02 - VLT
®
is a registered Danfoss trademark 77
4 4
