Danfoss VLT AutomationDrive Design Guide

Mains Supply 3 x 525- 690V AC
FC 302 P37K P45K P55K P75K P90K
High/ Normal Load* HO NO HO NO HO NO HO NO HO NO
Typical Shaft output at
550V [kW]
30 37 37 45 45 55 55 75 75 90
Typical Shaft output at
575V [HP]
40 50 50 60 60 75 75 100 100 125
Typical Shaft output at
690V [kW]
37 45 45 55 55 75 75 90 90 110
Enclosure IP21 D1 D1 D1 D1 D1
Enclosure IP54 D1 D1 D1 D1 D1
Enclosure IP00 D3 D3 D3 D3 D3
Output current
Continuous
(at 550V) [A]
48 56 56 76 76 90 90 113 113 137
Intermittent (60 sec
overload)
(at 550V) [A]
77 62 90 84 122 99 135 124 170 151
Continuous
(at 575/690V) [A]
46 54 54 73 73 86 86 108 108 131
Intermittent (60 sec
overload)
(at 575/690V) [A]
74 59 86 80 117 95 129 119 162 144
Continuous KVA
(at 550V) [KVA]
46 53 53 72 72 86 86 108 108 131
Continuous KVA
(at 575V) [KVA]
46 54 54 73 73 86 86 108 108 130
Continuous KVA
(at 690V) [KVA]
55 65 65 87 87 103 103 129 129 157
Max. input current
Continuous
(at 550V ) [A]
53 60 60 77 77 89 89 110 110 130
Continuous
(at 575V ) [A]
51 58 58 74 74 85 85 106 106 124
Continuous
(at 690V) [A]
50 58 58 77 77 87 87 109 109 128
Max. cable size, mains,
motor, load share and
brake [mm
2
(AWG)]
2x70 (2x2/0)
Max. external mains
fuses [A]
1
125 160 200 200 250
Estimated power loss
at 600V [W]
4)
1299 1398 1459 1645 1643 1827 1350 1599 1597 1891
Estimated power loss
at 690V [W]
4)
1002 1071 1071 1251 1251 1392 1392 1648 1650 1951
Weight,
enclosure IP21, IP54 [kg]
96
Weight,
enclosure IP00 [kg]
82
Efficiency
4)
0.97 0.97 0.98 0.98 0.98
Output frequency 0 - 600Hz
Heatsink overtemp. trip
90°C
Power card ambient trip
75°C
* High overload = 160% torque during 60 sec., Normal overload = 110% torque during 60 sec.
FC 300 Selection FC 300 Design Guide
76 MG.33.BD.02 - VLT
®
is a registered Danfoss trademark
44
