Danfoss VLT AutomationDrive Design Guide

Mains Supply 3 x 525- 690V AC
FC 302 P400 P500 P560
High/ Normal Load* HO NO HO NO HO NO
Typical Shaft output at 550V [kW] 315 400 400 450 450 500
Typical Shaft output at 575V [HP] 400 500 500 600 600 650
Typical Shaft output at 690V [kW] 400 500 500 560 560 630
Enclosure IP21 E1 E1 E1
Enclosure IP54 E1 E1 E1
Enclosure IP00 E2 E2 E2
Output current
Continuous
(at 550V) [A]
429 523 523 596 596 630
Intermittent (60 sec overload)
(at 550V) [A]
644 575 785 656 894 693
Continuous
(at 575/ 690V) [A]
410 500 500 570 570 630
Intermittent (60 sec overload)
(at 575/690V) [A]
615 550 750 627 855 693
Continuous KVA
(at 550V) [KVA]
409 498 498 568 568 600
Continuous KVA
(at 575V) [KVA]
408 498 498 568 568 627
Continuous KVA
(at 690V) [KVA]
490 598 598 681 681 753
Max. input current
Continuous
(at 550V ) [A]
413 504 504 574 574 607
Continuous
(at 575V) [A]
395 482 482 549 549 607
Continuous
(at 690V) [A]
395 482 482 549 549 607
Max. cable size, mains, motor and
load share [mm
2
(AWG)]
4x240 (4x500 mcm) 4x240 (4x500 mcm) 4x240 (4x500 mcm)
Max. cable size, brake [mm
2
(AWG)]
2 x 185
(2 x 350 mcm)
2 x 185
(2 x 350 mcm)
2 x 185
(2 x 350 mcm)
Max. external mains fuses [A]
1
700 900 900
Estimated power loss
at 600V [W]
4)
4478 5623 6153 7018 7007 7793
Estimated power loss
at 690V [W]
4)
4605 5794 6328 7221 7201 8017
Weight,
enclosure IP21, IP54 [kg]
263 272 313
Weight,
enclosure IP00 [kg]
221 236 277
Efficiency
4)
0.98
Output frequency 0 - 500Hz
Heatsink overtemp. trip
110°C
Power card ambient trip
75°C
* High overload = 160% torque during 60 sec., Normal overload = 110% torque during 60 sec.
FC 300 Selection FC 300 Design Guide
MG.33.BD.02 - VLT
®
is a registered Danfoss trademark 79
4 4
