Mains Supply 3 x 525- 690V AC
FC 302 P630 P710 P800
High/ Normal Load* HO NO HO NO HO NO
Typical Shaft output at 550V [kW] 500 560 560 670 670 750
Typical Shaft output at 575V [HP] 650 750 750 950 950 1050
Typical Shaft output at 690V [kW] 630 710 710 800 800 900
Enclosure IP21, 54 without/ with
options cabinet
F1/ F3 F1/ F3 F1/ F3
Output current
Continuous
(at 550V) [A]
659 763 763 889 889 988
Intermittent (60 sec overload)
(at 550V) [A]
989 839 1145 978 1334 1087
Continuous
(at 575/690V) [A]
630 730 730 850 850 945
Intermittent (60 sec overload)
(at 575/690V) [A]
945 803 1095 935 1275 1040
Continuous KVA
(at 550V) [KVA]
628 727 727 847 847 941
Continuous KVA
(at 575V) [KVA]
627 727 727 847 847 941
Continuous KVA
(at 690V) [KVA]
753 872 872 1016 1016 1129
Max. input current
Continuous
(at 550V ) [A]
642 743 743 866 866 962
Continuous
(at 575V) [A]
613 711 711 828 828 920
Continuous
(at 690V) [A]
613 711 711 828 828 920
Max. cable size, motor [mm
2
(AWG
2)
)]
8x150
(8x300 mcm)
Max. cable size,mains F1 [mm
2
(AWG
2)
)]
8x240
(8x500 mcm)
Max. cable size,mains F3 [mm
2
(AWG
2)
)]
8x456
(8x900 mcm)
Max. cable size, loadsharing [mm
2
(AWG
2)
)]
4x120
(4x250 mcm)
Max. cable size, brake [mm
2
(AWG
2)
)
4x185
(4x350 mcm)
Max. external mains fuses [A]
1
1600
Estimated power loss
at 600V [W]
4)
7586 8933 8683 10310 10298 11692
Estimated power loss
at 690V [W]
4)
7826 9212 8983 10659 10646 12080
F3/F4 Max added losses CB or
Disconnect & Contactor
342 427 419 532 519 615
Max panel options losses 400
Weight,
enclosure IP21, IP 54 [kg]
1004/ 1299 1004/ 1299 1004/ 1299
Weight, Rectifier Module [kg] 102 102 102
Weight, Inverter Module [kg] 102 102 136
Efficiency
4)
0.98
Output frequency 0-500 Hz
Heatsink overtemp. trip 95 °C 105 °C 95 °C
Power card ambient trip 75 °C
* High overload = 160% torque during 60 sec., Normal overload = 110% torque during 60 sec.
FC 300 Selection FC 300 Design Guide
80 MG.33.BD.02 - VLT
®
is a registered Danfoss trademark
44
