1-05 Hand Mode Configuration
Option: Function:
This parameter is only relevant when parameter 1-00
Configu-
ration Mode
is set to Process Closed Loop [3]. The parameter is
used for determining the reference or setpoint handling when
changing from Auto Mode to Hand Mode on the LCP.
[0] Speed Open Loop In Hand Mode the drive always runs in Open Loop configuration
regardless of setting in par. 1-00
Configuration Mode . Local po-
tentiometer (if present) or Arrow up/down determines output
frequency limited by Motor Speed High/Low Limit (parameters
4-14 and 4-12).
[2]
*
As configuration in
par. 1-00
If par. 1-00 Configuration Mode is set to Open Loop [1] function
is as described above.
If par. 1-00 is set to
Process Closed Loop [3] changing from Auto
mode to Hand mode results in a setpoint change via local po-
tentiometer or Arrow up/down. The change is limited by Refer-
ence Max/Min (parameters 3-02 and 3-03).
4.2.1. 1-2* Motor Data
Enter the correct motor nameplate data (power, voltage, frequency, current and speed).
Run AMT, see par. 1-29.
Factory settings for advanced motor data, par. 1-3*, are automatically calculated.
NB!
Parameters in parameter group 1.2* cannot be adjusted while motor runs.
1-20 Motor Power [kW]/[HP] (P
m.n
)
Range: Function:
Enter motor power from nameplate data.
[0.09 kW/0.12 HP -
11 kW/15 HP]
Two sizes down, one size up from nominal VLT rating.
NB!
Changing this parameter affects par. 1-22 to 1-25,
1-30, 1-33 and 1-35.
1-22 Motor Voltage (U
m.n
)
Range: Function:
230/400
V
[50 - 999 V] Enter motor voltage from nameplate data.
1-23 Motor Frequency (f
m.n
)
Range: Function:
50 Hz
*
[20-400 Hz] Enter motor frequency from nameplate data.
