4.5. Parameter Group 4: Limits/Warnings
4.5.1. 4-** Motor Limits
Parameter group for configuring limits and warning.
4.5.2. 4-1* Motor Limits
Use these parameters for defining the speed, torque and current working range for the motor.
4-10 Motor Speed Direction
Option: Function:
If terminals 96, 97 and 98 are connected to U, V and W respec-
tively, the motor runs clockwise when seen from the front.
NB!
This parameter cannot be adjusted while the mo-
tor is running
[0] Clockwise The motor shaft rotates in clockwise direction. This setting pre-
vents the motor from running in counterclockwise direction.
If par. 1-00
Configuration mode
has been set to
Process Closed
Loop
[3] this parameter must always be set to
Clockwise
.
[1] Counterclockwise The motor shaft rotates in counterclockwise direction. This set-
ting prevents the motor from running in clockwise direction.
[2]
*
Both With this setting the motor can run in both directions. However,
the output frequency is limited to the range: Motor Speed Low
Limit (par. 4-12) to Motor Speed High Limit (par. 4-14).
4-12 Motor Speed Low Limit
Range: Function:
0.0 Hz
*
[0.0 - 400.0 Hz] Set the
Minimum Motor Speed Limit
corresponding to the min-
imum output frequency of the motor shaft.
NB!
As the minimum output frequency is an absolute
value, it cannot be deviated from.
4-14 Motor Speed High Limit
Range: Function:
65.0
Hz
*
[0.0 - 400.0 Hz] Set the
Maximum Motor Speed
corresponding to the maximum
output frequency of the motor shaft.
NB!
As the maximum output frequency is an absolute
value, it cannot be deviated from.
4. Parameter Descriptions VLT Micro Drive FC 51
36
MG.02.C2.02 - VLT
®
is a registered Danfoss trademark
4
