Danfoss VLT FC 51 Series User Manual

4.13. Parameter Group 16: Data Readouts
4.13.1. 16-** Data Readouts
Parameter group for data read-outs, e.g. actual references, voltages, control, alarm, warning and
status words.
4.13.2. 16-0* General Status
Parameters for reading the general status, e.g. the calculated reference, the active control word,
status.
16-00 Control Word
Range: Function:
0
*
[0 - 65535] View latest valid control word sent to frequency converter via
serial communication port.
16-01 Reference [Unit]
Range: Function:
0.000
*
[-4999.000 -
4999.000]
View total remote reference. Total reference is sum of pulse,
analog, preset, LCP potmeter, local bus and freeze reference.
16-02 Reference %
Range: Function:
0.0
*
[-200.0 - 200.0%] View total remote reference in percent. Total reference is sum
of pulse, analog, preset, LCP potmeter, local bus and freeze
reference.
16-03 Status Word
Range: Function:
0
*
[0 - 65535] View status word sent to frequency converter via serial com-
munication port.
16-05 Main Actual Value %
Range: Function:
0.00
*
[-100.00 - 100.00%] View two-byte word sent with status word to bus Master re-
porting main actual value.
4.13.3. 16-1* Motor Status
Parameters for reading the motor status values.
16-10 Power [kW]
Range: Function:
0 kW
*
[0 - 99 kW] View output power in kW.
VLT Micro Drive FC 51 4. Parameter Descriptions
MG.02.C2.02 - VLT
®
is a registered Danfoss trademark 71
4

Danfoss VLT FC 51 Series Specifications

General

Enclosure	IP20
Operating Temperature	-10°C to +40°C (without derating), up to +50°C (with derating)
Output Voltage	0 to input voltage
Protection Features	Overcurrent, overvoltage, undervoltage, short circuit, overload, overtemperature, ground fault
Cooling Method	Forced convection
Input Voltage	200-240V AC, 380-480V AC
