16-36 Inv. Nom. Current
Range: Function:
0.00 A
*
[0.01 - 10000.00 A] View continuous nominal inverter current.
16-37 Inv. Max. Current
Range: Function:
0.00 A
*
[0.1 - 10000.00 A] View intermittent maximum inverter current (150%).
16-38 SL Controller State
Range: Function:
0
*
[0 - 255] View number of active SLC state.
4.13.5. 16-5* Ref. & Feedb.
Parameters for reporting the reference and feedback input.
16-50 External Reference
Range: Function:
0.0%
*
[-200.0 - 200.0%] View sum of all external references in percent.
16-51 Pulse Reference
Range: Function:
0.0 %
*
[-200.0 - 200.0%] View actual pulse input converted to a reference in percent.
16-52 Feedback
Range: Function:
0.000
*
[-4999.000 -
4999.000]
View analog or pulse feedback in Hz.
4.13.6. 16-6* Inputs and Outputs
Parameters for reporting the digital and analog IO ports.
16-60 Digital Input 18, 19, 27, 33
Range: Function:
0
*
[0 - 1111] View signal states from active digital inputs.
16-61 Digital Input 29
Range: Function:
0
*
[0 - 1] View signal state on digital input 29.
16-62 Analog Input 53 (volt)
Range: Function:
0.00
*
[0.00 - 10.00 V] View input voltage on analog input terminal.
VLT Micro Drive FC 51 4. Parameter Descriptions
MG.02.C2.02 - VLT
®
is a registered Danfoss trademark 73
4
