6-81 LCP Potmeter Low Ref. Value
Range: Function:
The scaling value corresponding to 0.
0.000
*
[-4999 - 4999] Enter low reference value.
The reference value corresponding to potentiometer turned fully
counterclockwise (0 degrees).
6-82 LCP Potmeter High Ref. Value
Range: Function:
The scaling value corresponding to the maximum reference
feedback value set in par. 3-03.
50.00
*
[-4999 - 4999] Enter high reference value.
The reference value corresponding to potentiometer turned fully
clockwise (200 degrees).
4.7.6. 6-9* Analog Output
These parameters are for configuring the analog outputs of the frequency converter.
6-90 Terminal 42 Mode
Option: Function:
[0]
*
0 - 20 mA Range for analog outputs is 0-20 mA
[1] 4-20 mA Range for analog outputs is 4 - 20 mA
[2] Digital Functions as slow reacting digital output. Set value to either 0
mA (off) or 20 mA (on), see par. 6-92.
6-91 Terminal 42 Analog Output
Option: Function:
Select the function for terminal 42 as an analog output.
[0]
*
No Operation
[10] Output Frequency
[11] Reference
[12] Feedback
[13] Motor Current
[16] Power
[17] Speed
6-92 Terminal 42 Digital Output
Option: Function:
See par. 5-4*,
Relays
, for choices and descriptions.
[80] SL Digital Output A See par. 13-52
SL Control Action
. When Smart Logic Action
Set
dig. out. A high
[38] is executed, input goes high. When Smart
Logic Action
Set dig. out. A low
[32] is executed, input goes low.
4. Parameter Descriptions VLT Micro Drive FC 51
48
MG.02.C2.02 - VLT
®
is a registered Danfoss trademark
