Adjustable frequency drive P18K P22K P30K P37K P45K P55K P75K P90K
Typical shaft output [kW] 18.5 22.0 30.0 37.0 45.0 55.0 75.0 90.0
Typical shaft output [hp] 25 30.0 40.0 50.0 60.0 70.0 100.0 125.0
IP54 frame I4 I6 I6 I6 I7 I7 I8 I8
Max. cable size in terminals (line power, motor)
[mm
2
/AWG]
16/6 35/2 35/2 35/2 50/1 50/1 95/(3/0) 120/(4/0)
Output current
104 °F [40 °C] ambient temperature
Continuous (3x380–440 V) [A] 37.0 44.0 61.0 73.0 90.0 106.0 147.0 177.0
Intermittent (3x380–440 V) [A] 40.7 48.4 67.1 80.3 99.0 116.6 161.7 194.7
Continuous (3x440–480 V) [A] 34.0 40.0 52.0 65.0 80.0 105.0 130.0 160.0
Intermittent (3x440–480 V) [A] 37.4 44.0 57.2 71.5 88.0 115.5 143.0 176.0
Max. input current
Continuous (3x380-440 V) [A] 35.2 41.8 57.0 70.3 84.2 102.9 140.3 165.6
Intermittent (3x380–440 V) [A] 38.7 46.0 62.7 77.4 92.6 113.1 154.3 182.2
Continuous (3x440–480 V) [A] 29.3 36.0 49.2 60.6 72.5 88.6 120.9 142.7
Intermittent (3 x 440–480 V) [A] 32.2 39.6 54.1 66.7 79.8 97.5 132.9 157.0
Max. electrical fuses
Estimated power loss [W], Best case/typical
1)
412/
456
496 734 995 840 1099 1520 1781
Weight enclosure IP54 [kg] 13.8 27 27 27 45 45 65 65
Efficiency [%], Best case/Typical
1)
98.1/
97.9
98.0 97.8 97.6 98.3 98.2 98.1 98.3
Output current
122 °F [50 °C] ambient temperature
Continuous (3x380–440 V) [A] 33.0 35.2 48.8 58.4 63.0 74.2 102.9 123.9
Intermittent (3x380–440 V) [A] 36.3 38.7 53.9 64.2 69.3 81.6 113.2 136.3
Continuous (3x440–480 V) [A] 30.0 32.0 41.6 52.0 56.0 73.5 91.0 112.0
Intermittent (3x440–480 V) [A] 33.0 35.2 45.8 57.2 61.6 80.9 100.1 123.2
Table 8.7 P18K–P90K
1) At rated load conditions
