8.2 General Specifications
Protection and features
•
Electronic thermal motor protection against overload.
•
Temperature monitoring of the heatsink ensures that the adjustable frequency drive trips in case of overtem-
perature.
•
The adjustable frequency drive is protected against short-circuits between motor terminals U, V, W.
•
When a motor phase is missing, the adjustable frequency drive trips and issues an alarm.
•
When a line phase is missing, the adjustable frequency drive trips or issues a warning (depending on the load).
•
Monitoring of the intermediate circuit voltage ensures that the adjustable frequency drive trips when the
intermediate circuit voltage is too low or too high.
•
The adjustable frequency drive is protected against ground faults on motor terminals U, V, W.
Line power supply (L1, L2, L3)
Supply voltage 200–240 V ±10%
Supply voltage 380–480 V ±10%
Supply voltage 525–600 V ±10%
Supply frequency 50/60 Hz
Max. temporary imbalance between line phases 3.0% of rated supply voltage
True Power Factor (λ) ≥ 0.9 nominal at rated load
Displacement Power Factor (cosφ) near unity (>0.98)
Switching on the input supply L1, L2, L3 (power-ups) enclosure frame H1-H5, I2, I3, I4 Max. 2 times/min.
Switching on the input supply L1, L2, L3 (power-ups) enclosure frame H6-H8, I6-I8 Max. 1 time/min.
Environment according to EN 60664-1 overvoltage category III/pollution degree 2
The unit is suitable for use on a circuit capable of delivering not more than 100,000 RMS symmetrical Amperes, 240/480 V
maximum.
Motor output (U, V, W)
Output voltage 0–100% of supply voltage
Output frequency 0–200 Hz (VVC
plus
), 0–400 Hz (u/f)
Switching on output Unlimited
Ramp times 0.05–3600 s
Cable lengths and cross-sections
Max. motor cable length, shielded/armored (EMC-compatible installation) See chapter 2.8.2 EMC Test Results
Max. motor cable length, non-shielded/unarmored 50 m
Max. cross-section to motor, line power*
Cross-section DC terminals for filter feedback on enclosure frame H1-H3, I2, I3, I4 4 mm
2
/11 AWG
Cross-section DC terminals for filter feedback on enclosure frame H4-H5 16 mm
2
/6 AWG
Maximum cross-section to control terminals, rigid wire 2.5 mm
2
/14 AWG)
Maximum cross-section to control terminals, flexible cable 2.5 mm
2
/14 AWG)
Minimum cross-section to control terminals 0.05 mm
2
/30 AWG
*See chapter 8.1.2 Line Power Supply 3x380–480 V AC for more information.
