Changes Made
Changes Made lists all parameters changed since factory
setting. Only the changed parameters in current edit-setup
are listed in changes made.
If the parameter's value is changed back to the factory
settings from another different value, the parameter will
NOT be listed in Changes Made.
1. Press [Menu] to enter the Quick Menu until
indicator in display is placed above Quick Menu.
2.
Press [
] [
] to select either wizard, closed-loop
set-up, motor set-up or changes made, then press
[OK].
3.
Press [
] [
] to browse through the parameters
in the Quick Menu.
4. Press [OK] to select a parameter.
5.
Press [
] [
] to change the value of a parameter
setting.
6. Press [OK] to accept the change.
7. Press either [Back] twice to enter “Status”, or
press [Menu] once to enter “Main Menu”.
6.3.4
Main Menu
[Main Menu] is used for access to and programming of all
parameters. The Main Menu parameters can be accessed
readily unless a password has been created via 0-60 Main
Menu Password.
For the majority of VLT
®
HVAC Basic Drive applications, it
is not necessary to access the Main Menu parameters but
instead the Quick Menu provides the simplest and quickest
access to the typical required parameters.
The Main Menu accesses all parameters.
1. Press [Menu] until indicator in display is placed
above “Main Menu”.
2.
Press [
] [
] to browse through the parameter
groups.
3. Press [OK] to select a parameter group.
4.
Press [
] [
] to browse through the parameters
in the specific group.
5. Press [OK] to select the parameter.
6.
Press [
] [
] to set/change the parameter value.
Press [Back] to go back one level.
6.4
Quick Transfer of Parameter Settings
between Multiple Adjustable Frequency
Drives
Once the set-up of an adjustable frequency drive is
complete, Danfoss recommends to store the data in the
LCP or on a PC via MCT 10 Set-up Software tool.
Data transfer from adjustable frequency drive to LCP:
WARNING
Stop the motor before performing this operation.
1.
Go to 0-50 LCP Copy
2. Press [OK]
3.
Select [1] All to LCP
4. Press [OK]
Connect the LCP to another adjustable frequency drive
and copy the parameter settings to this adjustable
frequency drive as well.
Data transfer from LCP to adjustable frequency drive:
WARNING
Stop the motor before performing this operation.
1.
Go to 0-50 LCP Copy
2. Press [OK]
3.
Select [2] All from LCP
4. Press [OK]
6.5
Readout and Programming of Indexed
Parameters
Select the parameter, press [OK], and press [
]/[
] to scroll
through the indexed values. To change the parameter
value, select the indexed value and press [OK]. Change the
value by pressing [
]/[
]. Press [OK] to accept the new
setting. Press [Cancel] to abort. Press [Back] to leave the
parameter.
How to Program Design Guide
84 Danfoss A/S © Rev. 2014-01-14 All rights reserved. MG18C522
