8.4 dU/Dt
Cable length
(ft [m])
AC line voltage [V] Rise time [usec]
V
peak
[kV]
dU/dt [kV/usec]
200 V 0.36 hp [0.25 kW]
16.4 [5] 240 0.121 0.498 3.256
82 [25] 240 0.182 0.615 2.706
164 [50] 240 0.258 0.540 1.666
200 V 0.5 hp [0.37 kW]
16.4 [5] 240 0.121 0.498 3.256
82 [25] 240 0.182 0.615 2.706
164 [50] 240 0.258 0.540 1.666
200 V 1 hp [0.75 kW]
16.4 [5] 240 0.121 0.498 3.256
82 [25] 240 0.182 0.615 2.706
164 [50] 240 0.258 0.540 1.666
200 V 2 hp [1.5 kW]
16.4 [5] 240 0.121 0.498 3.256
82 [25] 240 0.182 0.615 2.706
164 [50] 240 0.258 0.540 1.666
200 V 3 hp [2.2 kW]
16.4 [5] 240 0.18 0.476 2.115
82 [25] 240 0.230 0.615 2.141
164 [50] 240 0.292 0.566 1.550
200 V 5 hp [3.7 kW]
16.4 [5] 240 0.168 0.570 2.714
82 [25] 240 0.205 0.615 2.402
164 [50] 240 0.252 0.620 1.968
200 V 7.5 hp [5.5 kW]
16.4 [5] 240 0.128 0.445 2781
82 [25] 240 0.224 0.594 2121
164 [50] 240 0.328 0.596 1454
200 V 10 hp [7.5 kW]
16.4 [5] 240 0.18 0.502 2244
82 [25] 240 0.22 0.598 2175
164 [50] 240 0.292 0.615 1678
200 V 15 hp [11 kW]
118 [36] 240 0.176 0.56 2545
164 [50] 240 0.216 0.599 2204
400 V 5 hp [0.37 kW]
16.4 [5] 400 0.160 0.808 4.050
82 [25] 400 0.240 1.026 3.420
164 [50] 400 0.340 1.056 2.517
400 V 1 hp [0.75 kW]
16.4 [5] 400 0.160 0.808 4.050
82 [25] 400 0.240 1.026 3.420
164 [50] 400 0.340 1.056 2.517
400 V 2 hp [1.5 kW]
16.4 [5] 400 0.160 0.808 4.050
82 [25] 400 0.240 1.026 3.420
164 [50] 400 0.340 1.056 2.517
400 V 3 hp [2.2 kW]
16.4 [5] 400 0.190 0.760 3.200
82 [25] 400 0.293 1.026 2.801
164 [50] 400 0.422 1.040 1.971
400 V 5 hp [3.0 kW]
16.4 [5] 400 0.190 0.760 3.200
82 [25] 400 0.293 1.026 2.801
164 [50] 400 0.422 1.040 1.971
400 V 5 hp [4.0 kW]
16.4 [5] 400 0.190 0.760 3.200
82 [25] 400 0.293 1.026 2.801
164 [50] 400 0.422 1.040 1.971
400 V 7.5 hp [5.5 kW]
16.4 [5] 400 0.168 0.81 3.857
82 [25] 400 0.239 1.026 3.434
164 [50] 400 0.328 1.05 2.560
General Specifications and ... Design Guide
118 Danfoss A/S © Rev. 2014-01-14 All rights reserved. MG18C522
