Danfoss VLT HVAC Basic Drive FC 101 Design Guide

Cable length
(ft [m])
AC line voltage [V] Rise time [usec]
V
peak
[kV]
dU/dt [kV/usec]
400 V 10 hp [7.5 kW]
16.4 [5] 400 0.168 0.81 3.857
82 [25] 400 0.239 1.026 3.434
164 [50] 400 0.328 1.05 2.560
400 V 15 hp [11 kW]
16.4 [5] 400 0.116 0.69 4871
82 [25] 400 0.204 0.985 3799
164 [50] 400 0.316 1.01 2563
400 V 20 hp [15 kW]
16.4 [5] 400 0.139 0.864 4.955
164 [50] 400 0.338 1.008 2.365
400 V 25 hp [18.5 kW]
16.4 [5] 400 0.132 0.88 5.220
82 [25] 400 0.172 1.026 4.772
164 [50] 400 0.222 1.00 3.603
400 V 30 hp [22 kW]
16.4 [5] 400 0.132 0.88 5.220
82 [25] 400 0.172 1.026 4.772
164 [50] 400 0.222 1.00 3.603
400 V 40 hp [30 kW]
32.8 [10] 400 0.376 0.92 1.957
164 [50] 400 0.536 0.97 1.448
328 [100] 400 0.696 0.95 1.092
492 [150] 400 0.8 0.965 0.965
32.8 [10] 480 0.384 1.2 2.5
164 [50] 480 0.632 1.18 1.494
328 [100] 480 0.712 1.2 1.348
492 [150] 480 0.832 1.17 1.125
32.8 [10] 500 0.408 1.24 2.431
164 [50] 500 0.592 1.29 1.743
328 [100] 500 0.656 1.28 1.561
492 [150] 500 0.84 1.26 1.2
400 V 50 hp [37 kW]
32.8 [10] 400 0.276 0.928 2.69
164 [50] 400 0.432 1.02 1.889
32.8 [10] 480 0.272 1.17 3.441
164 [50] 480 0.384 1.21 2.521
32.8 [10] 500 0.288 1.2 3.333
164 [50] 500 0.384 1.27 2.646
400 V 60 hp [45 kW]
32.8 [10] 400 0.3 0.936 2.496
164 [50] 400 0.44 0.924 1.68
328 [100] 400 0.56 0.92 1.314
492 [150] 400 0.8 0.92 0.92
32.8 [10] 480 0.3 1.19 3.173
164 [50] 480 0.4 1.15 2.3
328 [100] 480 0.48 1.14 1.9
492 [150] 480 0.72 1.14 1.267
32.8 [10] 500 0.3 1.22 3.253
164 [50] 500 0.38 1.2 2.526
328 [100] 500 0.56 1.16 1.657
492 [150] 500 0.74 1.16 1.254
400 V 75 hp [55 kW] 32.8 [10]
400 0.46 1.12 1.948
480 0.468 1.3 2.222
400 V 100 hp [75 kW] 32.8 [10]
400 0.502 1.048 1.673
480 0.52 1.212 1.869
500 0.51 1.272 1.992
General Specifications and ... Design Guide
MG18C522 Danfoss A/S © Rev. 2014-01-14 All rights reserved. 119
