Page #118 background imageLoading...
Page #118 background image
Control card, 24 V DC output
Terminal number 12
Max. load 80 mA
Relay output
Programmable relay output 2
Relay 01 and 02 01-03 (NC), 01-02 (NO), 04-06 (NC), 04-05 (NO)
Max. terminal load (AC-1)
1)
on 01-02/04-05 (NO) (Resistive load) 250 V AC, 3 A
Max. terminal load (AC-15)
1)
on 01-02/04-05 (NO) (Inductive load @ cosφ 0.4) 250 V AC, 0.2 A
Max. terminal load (DC-1)
1)
on 01-02/04-05 (NO) (Resistive load) 30 V DC, 2 A
Max. terminal load (DC-13)
1)
on 01-02/04-05 (NO) (Inductive load) 24 V DC, 0.1 A
Max. terminal load (AC-1)
1)
on 01-03/04-06 (NC) (Resistive load) 250 V AC, 3 A
Max. terminal load (AC-15)
1)
on 01-03/04-06 (NC) (Inductive load @ cosφ 0.4) 250 V AC, 0.2 A
Max. terminal load (DC-1)
1)
on 01-03/04-06
(NC) (Resistive load)
30 V DC, 2 A
Min. terminal load on 01-03 (NC), 01-02 (NO) 24 V DC 10 mA, 24 V AC 20 mA
Environment according to EN 60664-1 Overvoltage category III/pollution degree 2
1)
IEC 60947 parts 4 and 5.
Control card, 10 V DC output
A)
Terminal number 50
Output voltage 10.5 V ±0.5 V
Max. load 25 mA
A)
All inputs, outputs, circuits, DC supplies and relay contacts are galvanically isolated from the supply voltage (PELV) and
other high-voltage terminals.
Surroundings
Enclosure IP20
Enclosure kit available. IP21, TYPE 1
Vibration test 1.0 g
Max. relative humidity 5%–95% (IEC 60721-3-3; Class 3K3 (non-condensing) during operation
Aggressive environment (IEC 60721-3-3), coated (standard) frame H1-H5 Class 3C3
Aggressive environment (IEC 60721-3-3), non-coated frame H6-H10 Class 3C2
Aggressive environment (IEC 60721-3-3), coated (optional) frame H6-H10 Class 3C3
Aggressive environment (IEC 60721-3-3), non-coated frame I2–I8 Class 3C2
Test method according to IEC 60068-2-43 H2S (10 days)
Ambient temperature See max. output current at 104/122 °F [40/50 °C] in chapter 8.1.2 Line Power Supply 3x380–480 V AC
Derating for high ambient temperature, see chapter 8.5 Derating according to Ambient Temperature and Switching
Frequencychapter 8.5 Derating according to Ambient Temperature and Switching Frequency.
Minimum ambient temperature during full-scale operation 32 °F [0 °C]
Minimum ambient temperature at reduced performance -4 °F [-20 °C]
Minimum ambient temperature at reduced performance 14 °F [-10 °C]
Temperature during storage/transport -22 to +149/158 °F [-30 to +65/70 °C]
Maximum altitude above sea level without derating 3,300 ft [1000 m]
Maximum altitude above sea level with derating 10,000 ft [3000 m]
Derating for high altitude, see
Safety standards EN/IEC 61800-5-1, UL 508C
EMC standards, Emission EN 61800-3, EN 61000-6-3/4, EN 55011, IEC 61800-3
EMC standards,
Immunity
EN 61800-3, EN 61000-3-12, EN 61000-6-1/2, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN
61000-4-5, EN 61000-4-6
General Specifications and ... Design Guide
116 Danfoss A/S © Rev. 2014-01-14 All rights reserved. MG18C522
