2.6.20 Primary Pumps
Primary pumps in a primary/secondary pumping system can be used to maintain a constant flow through devices that
encounter operation or control difficulties when exposed to variable flow. The primary/secondary pumping technique
decouples the “primary” production loop from the “secondary” distribution loop. This allows devices such as chillers to
obtain constant design flow and operate properly while allowing the rest of the system to vary in flow.
As the evaporator flow rate decreases in a chiller, the chilled water begins to become over-chilled. As this happens, the
chiller attempts to decrease its cooling capacity. If the flow rate drops far enough, or too quickly, the chiller cannot shed its
load sufficiently and the chiller’s safety trips the chiller requiring a manual reset. This situation is common in large instal-
lations especially when two or more chillers are installed in parallel if primary/secondary pumping is not utilized.
2.6.21 The VLT Solution
Depending on the size of the system and the size of the primary loop, the energy consumption of the primary loop can
become substantial.
An adjustable frequency drive can be added to the primary system to replace the throttling valve and/or trimming of the
impellers, leading to reduced operating expenses. Two control methods are common:
Flow meter
Because the desired flow rate is known and constant, a flow meter installed at the discharge of each chiller can be used to
control the pump directly. Using the built-in PI controller, the adjustable frequency drive always maintains the appropriate
flow rate, even compensating for the changing resistance in the primary piping loop as chillers and their pumps are staged
on and off.
Local speed determination
The operator simply decreases the output frequency until the design flow rate is achieved.
Using an adjustable frequency drive to decrease the pump speed is very similar to trimming the pump impeller, except it
does not require any labor and the pump efficiency remains higher. The balancing contractor simply decreases the speed of
the pump until the proper flow rate is achieved and leaves the speed fixed. The pump operates at this speed any time the
chiller is staged on. Because the primary loop does not have control valves or other devices that can cause the system curve
to change and the variance due to staging pumps and chillers on and off is usually small, this fixed speed remains
appropriate. In the event the flow rate needs to be increased later in the life of the system, the adjustable frequency drive
can simply increase the pump speed instead of requiring a new pump impeller.
Product Overview Design Guide
MG18C522 Danfoss A/S © Rev. 2014-01-14 All rights reserved. 23
