4.1.2 Type Code String
F C - P T H
130BB899.10
X S A B CX X X X
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 302221 23 272524 26 28 29 31 373635343332 38 39
X0 D
1
1
X
X
X
X X X
X X X
Figure 4.1 Type Code
Description Pos. Possible choice
Product group & FC series 1–6 FC 101
Power rating 7–10 0.25–90 kW (PK25–P90K)
Number of phases 11 Three phases (T)
AC line voltage 11–12 T2: 200–240 V AC
T4: 380–480 V AC
T6: 525–600 V AC
Enclosure 13–15 E20: IP20/Chassis
P20: IP20/Chassis with backplate
E5A: IP54
P5A: IP54 with backplate
RFI filter 16–17 H1: RFI filter class A1/B
H2: RFI filter class A2
H3: RFI filter class A1/B (reduced cable length)
H4: RFI filter class A1
Brake 18 X: No brake chopper included
Display 19 A: Alpha Numeric Local Control Panel
X: No Local Control Panel
Coating PCB 20 X: No coated PCB
C: Coated PCB
Line power option 21 X: No line power option
Adaption 22 X: No adaption
Adaption 23 X: No adaption
Software release 24–27 SXXXX: Latest release - standard software
Software language 28 X: Standard
A options 29–30 AX: No A options
B options 31–32 BX: No B options
C0 options MCO 33–34 CX: No C options
C1 options 35 X: No C1 options
C option software 36–37 XX: No options
D options 38–39 DX: No D0 options
Table 4.1 Type Code Descriptions
How to Order Design Guide
50 Danfoss A/S © Rev. 2014-01-14 All rights reserved. MG18C522
44
