5-01 Terminal 27 Mode
Option: Function:
[0] * Input Defines terminal 27 as a digital input.
[1] Output Defines terminal 27 as a digital output.
Please note that this parameter cannot be adjusted while the motor is running.
5-02 Terminal 29 Mode
Option: Function:
[0] * Input Defines terminal 29 as a digital input.
[1] Output Defines terminal 29 as a digital output.
This parameter cannot be adjusted while the motor is running.
5-12 Terminal 27 Digital Input
Same options and functions as par. 5-1*, except for
Pulse input
.
Option: Function:
[0] * No operation
5-13 Terminal 29 Digital Input
Same options and functions as par. 5-1*.
Option: Function:
[14] * Jog
5-14 Terminal 32 Digital Input
Same options and functions as par. 5-1*, except for
Pulse input
.
Option: Function:
[0] * No operation
5-15 Terminal 33 Digital Input
Same options and functions as par. 5-1* Digital Inputs.
Option: Function:
[0] * No operation
5-40 Function Relay
Array [8]
(Relay 1 [0], Relay 2 [1]
Option MCB 105: Relay 7 [6], Relay 8 [7] and Relay 9 [8]).
Select options to define the function of the relays.
The selection of each mechanical relay is realized in an array parameter.
Option: Function:
[0] * No operation
Array [8] (Relay 1 [0], Relay 2 [1]
Option MCB 105: Relay 7 [6], Relay 8 [7] and Relay 9 [8])
[1] Control ready
[2] Drive ready
[3] Drive rdy/rem ctrl
[4] Standby / no warning
7 How to Program the Adjustable Frequency
Drive
VLT
®
HVAC Drive Instruction Manual
7-24
MG.11.AB.22 - VLT
®
