[2157] Ext. 3 Reference [Unit] The value of the reference for extended Closed-loop Controller 3
[2158] Ext. 3 Feedback [Unit] The value of the feedback signal for extended Closed-loop Controller 3
[2159] Ext. 3 Output [%] The value of the output from extended Closed-loop Controller 3
[2230] No-Flow Power The calculated No-Flow Power for the actual operating speed
[2316] Maintenance Text
[2580] Cascade Status Status for the operation of the cascade controller
[2581] Pump Status Status for the operation of each individual pump controlled by the cascade controller
[3110] Bypass Status Word
[3111] Bypass Running Hours
[9913]
[9914]
[9920] HS Temp. (PC1)
[9921] HS Temp. (PC2)
[9922] HS Temp. (PC3)
[9923] HS Temp. (PC4)
[9924] HS Temp. (PC5)
[9925] HS Temp. (PC6)
[9926] HS Temp. (PC7)
[9927] HS Temp. (PC8)
NOTE!
Please consult the VLT HVAC Drive
Programming Guide, MG.11.CX.YY
for detailed information.
0-21 Display Line 1.2 Small
Select a variable for display in line 1, middle position.
Option: Function:
[1614] * Motor Current
The options are the same as those listed in par. 0-20
Display Line 1.1 Small
.
0-22 Display Line 1.3 Small
Option: Function:
Select a variable for display in line 1, right position.
The options are the same as those listed under 0-2*.
0-23 Display Line 2 Large
Option: Function:
Select a variable for display in line 2.
The options are the same as those listed under 0-2*.
VLT
®
HVAC Drive Instruction Manual
7 How to Program the Adjustable Frequency
Drive
MG.11.AB.22 - VLT
®
is a registered Danfoss trademark
7-11
7
