Page #113 background imageLoading...
Page #113 background image
[140] ft/s
[141] ft/min
[145] ft
[160] °F
[170] psi
[171] lb/in²
[172] in. wtr. gage
[173] ft WG
[174] in Hg
[180] HP
NOTE!
This parameter is only available when using pressure to temperature feedback conversion.
If the choice Linear [0] is selected in par. 20-01
Feedback 1 Conversion
, then the setting of any choice in par. 20-02
Feedback 1 Source
Unit
does not matter as conversion will be one-to-one.
20-03 Feedback 2 Source
Option: Function:
See par. 20-00
Feedback 1 Source
for details.
[0] * No function
[1] Analog input 53
[2] Analog input 54
[3] Pulse input 29
[4] Pulse input 33
[7] Analog input X30/11
[8] Analog input X30/12
[9] Analog Input X42/1
[10] Analog Input X42/3
[11] Analog Input X42/5
[100] Bus feedback 1
[101] Bus feedback 2
[102] Bus feedback 3
20-04 Feedback 2 Conversion
Option: Function:
See par. 20-01
Feedback 1 Conversion
for details.
[0] * Linear
[1] Square root
[2] Pressure to temperature
[3]
[4]
20-05 Feedback 2 Source Unit
Option: Function:
See par. 20-02
Feedback 1 Source Unit
for details.
VLT
®
HVAC Drive Instruction Manual
7 How to Program the Adjustable Frequency
Drive
MG.11.AB.22 - VLT
®
is a registered Danfoss trademark
7-35
