Danfoss VLT HVACDrive User Manual

0-24 Display Line 3 Large
Select a variable for display in line 3.
Option: Function:
[1502] * kWh Counter
The options are the same as listed for par. 0-20
Display Line 1.1 Small .
0-37 Display Text 1
Range: Function:
0 N/A* [0 - 0 N/A] In this parameter, it is possible to write an individual text string for display in the LCP or to be read
via serial communication. If it is to be displayed permanently, select Display Text 1 in
par. 0-20
Display Line 1.1 Small , par. 0-21 Display Line 1.2 Small , par. 0-22 Display Line 1.3
Small
, par. 0-23 Display Line 2 Large or par. 0-24 Display Line 3 Large . Use the
▲
or
▼
buttons on
the LCP to change a character. Use the
◀
and
▶
buttons to move the cursor. When a character is
highlighted by the cursor, it can be changed. Use the
▲
or
▼
buttons on the LCP to change a
character. A character can be inserted by placing the cursor between two characters and pressing
▲
or
▼
.
0-38 Display Text 2
Range: Function:
0 N/A* [0 - 0 N/A] In this parameter, it is possible to write an individual text string for display in the LCP or to be read
via serial communication. If to be displayed permanently select Display Text 2 in par. 0-20
Display
Line 1.1 Small
, par. 0-21 Display Line 1.2 Small , par. 0-22 Display Line 1.3 Small , par. 0-23 Display
Line 2 Large
or par. 0-24 Display Line 3 Large . Use the
▲
or
▼
buttons on the LCP to change a
character. Use the
◀
and
▶
buttons to move the cursor. When a character is highlighted by the
cursor, this character can be changed. A character can be inserted by placing the cursor between
two characters and pressing
▲
or
▼
.
0-39 Display Text 3
Range: Function:
0 N/A* [0 - 0 N/A] In this parameter, it is possible to write an individual text string for display in the LCP or to be read
via serial communication. If it is to be displayed permanently, select Display Text 3 in
par. 0-20
Display Line 1.1 Small ,par. 0-21 Display Line 1.2 Small , par. 0-22 Display Line 1.3 Small ,
par. 0-23
Display Line 2 Large or par. 0-24 Display Line 3 Large . Use the
▲
or
▼
buttons on the
LCP to change a character. Use the
◀
and
▶
buttons to move the cursor. When a character is
highlighted by the cursor, this character can be changed. A character can be inserted by placing the
cursor between two characters and pressing
▲
or
▼
.
0-70 Date and Time
Range: Function:
Application
dependent*
[Application dependant]
7 How to Program the Adjustable Frequency
Drive
VLT
®
HVAC Drive Instruction Manual
7-12 MG.11.AB.22 - VLT
®
is a registered Danfoss trademark
7
