5.1.5 Tips and Tricks
* For the majority of HVAC applications, the Quick Menu, Quick Set-up and Function Set-up provide the simplest and quickest
access to all the typical parameters required.
* Whenever possible, performing an AMA will ensure best shaft performance
*
The contrast of the display can be adjusted by pressing [Status] and [
▲
] for a darker display or by pressing [Status] and [
▼
]
for a brighter display
* Under [Quick Menu] and [Changes Made] all parameters that have been changed from the factory settings are displayed
* Press and hold the [Main Menu] key for 3 seconds to access any parameter.
* For service purposes, it is recommended to copy all parameters to the LCP, see par. 0-50
LCP Copy
for further information.
Table 5.2: Tips and tricks
5.1.6 Quick Transfer of Parameter Settings when using GLCP
Once the set-up of an adjustable frequency drive is complete, it is recommended to store (backup) the parameter settings in the GLCP or on a PC via
MCT 10 Set-up Software Tool.
Stop the motor before performing any of these operations,.
Data storage in LCP:
1. Go to par. 0-50
LCP Copy
2. Press the [OK] key.
3. Select “All to LCP”
4. Press the [OK] key.
All parameter settings are now stored in the GLCP indicated by the progress bar. When 100% is reached, press [OK].
The GLCP can now be connected to another adjustable frequency drive and the parameter settings copied to this adjustable frequency drive.
Data transfer from LCP to adjustable frequency drive:
1. Go to par. 0-50
LCP Copy
2. Press the [OK] key.
3. Select “All from LCP”
4. Press the [OK] key.
The parameter settings stored in the GLCP are now transferred to the adjustable frequency drive indicated by the progress bar. When 100% is reached,
press [OK].
5 Commissioning and Application Examples VLT
®
HVAC Drive Instruction Manual
5-6
MG.11.AB.22 - VLT
®
is a registered Danfoss trademark
5
