0-20 Display Line 1.1 Small
Option: Function:
Select a variable for display in line 1, left position.
[0] None No display value selected
[37] Display Text 1 Enables an individual text string to be written, for display in the LCP or to be read via serial com-
munication.
[38] Display Text 2 Enables an individual text string to be written, for display in the LCP or to be read via serial com-
munication.
[39] Display Text 3 Enables an individual text string to be written, for display in the LCP or to be read via serial com-
munication.
[89] Date and Time Readout Displays the current date and time.
[953] Profibus Warning Word Displays Profibus communication warnings.
[1005] Readout Transmit Error Counter View the number of CAN control transmission errors since the last power-up.
[1006] Readout Receive Error Counter View the number of CAN control receipt errors since the last power-up.
[1007] Readout Bus Off Counter View the number of Bus Off events since the last power-up.
[1013] Warning Parameter View a DeviceNet-specific warning word. One separate bit is assigned to every warning.
[1115] LON Warning Word Shows the LON-specific warnings.
[1117] XIF Revision Shows the version of the external interface file of the Neuron C chip on the LON option.
[1118] LonWorks Revision Shows the software version of the application program of the Neuron C chip on the LON option.
[1501] Running Hours View the number of running hours of the motor.
[1502] kWh Counter View the line power consumption in kWh.
[1600] Control Word View the control word sent from the adjustable frequency drive via the serial communication port
in hex code.
[1601] Reference [Unit] Total reference (sum of digital/analog/preset/bus/freeze ref./catch up and slow-down) in selected
unit.
[1602] * Reference % Total reference (sum of digital/analog/preset/bus/freeze ref./catch up and slow-down) in percent.
[1603] Status Word Present status word
[1605] Main Actual Value [%] View the two-byte word sent with the status word to the bus master reporting the main actual value.
[1609] Custom Readout View the user-defined readouts as defined in par. 0-30
Custom Readout Unit
, par. 0-31
Custom
Readout Min Value
and par. 0-32
Custom Readout Max Value
.
[1610] Power [kW] Actual power consumed by the motor in kW.
[1611] Power [hp] Actual power consumed by the motor in HP.
[1612] Motor voltage Voltage supplied to the motor.
[1613] Frequency Motor frequency, i.e., the output frequency from the adjustable frequency drive in Hz.
[1614] Motor Current Phase current of the motor measured as effective value.
[1615] Frequency [%] Motor frequency, i.e., the output frequency from the adjustable frequency drive in percent.
[1616] Torque [Nm] Present motor load as a percentage of the rated motor torque.
7 How to Program the Adjustable Frequency
Drive
VLT
®
HVAC Drive Instruction Manual
7-8
MG.11.AB.22 - VLT
®
is a registered Danfoss trademark
7
