Page #108 background image
6-50 Terminal 42 Output
Option: Function:
Select the function of Terminal 42 as an analog current output. A motor current of 20 mA corre-
sponds to I
max
.
[0] * No operation
[100] Output freq. 0-100 : 0–100 Hz, (0–20 mA)
[101] Reference Min-Max : Minimum reference - Maximum reference, (0–20 mA)
[102] Feedback +-200% : -200% to +200% of par. 20-14
Maximum Reference/Feedb.
, (0–20 mA)
[103] Motor cur. 0-Imax : 0 - Inverter Max. Current (par. 16-37
Inv. Max. Current
), (0–20 mA)
[104] Torque 0-Tlim : 0 - Torque limit (par. 4-16
Torque Limit Motor Mode
), (0–20 mA)
[105] Torque 0-Tnom : 0 - Motor rated torque, (0–20 mA)
[106] Power 0-Pnom : 0 - Motor rated power, (0–20 mA)
[107] * Speed 0-HighLim : 0 - Speed High Limit (par. 4-13
Motor Speed High Limit [RPM]
and par. 4-14
Motor Speed High
Limit [Hz]
), (0–20 mA)
[113] Ext. Closed-loop 1 : 0–100%, (0–20 mA)
[114] Ext. Closed-loop 2 : 0–100%, (0–20 mA)
[115] Ext. Closed-loop 3 : 0–100%, (0–20 mA)
[130] Out fr 0-100 4-20 : 0–100 Hz
[131] Reference 4-20mA : Minimum Reference - Maximum Reference
[132] Feedback 4-20mA : -200% to +200% of par. 20-14
Maximum Reference/Feedb.
[133] Motor cur. 4-20mA : 0 - Inverter Max. Current (par. 16-37
Inv. Max. Current
)
[134] Torq.0-lim 4-20mA : 0 - Torque limit (par. 4-16
Torque Limit Motor Mode
)
[135] Torq.0-nom 4-20mA : 0 - Motor rated torque
[136] Power 4-20mA : 0 - Motor rated power
[137] Speed 4-20mA : 0 - Speed High Limit (4-13 and 4-14)
[139] Bus ctrl. : 0–100%, (0–20 mA)
[140] Bus ctrl. 4-20 mA : 0 - 100%
[141] Bus ctrl t.o. : 0–100%, (0–20 mA)
[142] Bus ctrl 4-20mA t.o. : 0 - 100%
[143] Ext. CL 1 4-20 mA : 0 - 100%
[144] Ext. CL 2 4-20 mA : 0 - 100%
[145] Ext. CL 3 4-20 mA : 0 - 100%
NOTE!
Values for setting the minimum reference are found in open-loop par. 3-02
Minimum Reference
and for closed-loop par. 20-13
Minimum Reference/
Feedb.
- values for maximum reference for open-loop are found in par. 3-03
Maximum Reference
and for closed-loop par. 20-14
Maximum Reference/
Feedb.
.
7 How to Program the Adjustable Frequency
Drive
VLT
®
HVAC Drive Instruction Manual
7-30
MG.11.AB.22 - VLT
®
is a registered Danfoss trademark
7
