Danfoss VLT HVACDrive User Manual

Line Power Supply 3 x 380–480 V AC - Normal overload 110% for 1 minute Adjustable frequency drive Typical Shaft Output [kW]
P1K1
1.1
P1K5
1.5
P2K2
2.2
P3K0
3
P4K0
4
P5K5
5.5
P7K5
7.5
Typical Shaft Output [HP] at 460 V 1.5 2.0 2.9 4.0 5.0 7.5 10 IP 20 / Chassis (A2+A3 may be converted to IP21 using a conversion kit. (Please see also items
Mechanical mount-
ing
in the instruction manual and
IP 21/Type 1 Enclosure kit
in the Design Guide.))
A2 A2 A2 A2 A2 A3 A3
IP 55 / NEMA 12 A5 A5 A5 A5 A5 A5 A5 IP 66 / NEMA 12 A5 A5 A5 A5 A5 A5 A5 Output current
Continuous (3 x 380–440 V) [A] 3 4.1 5.6 7.2 10 13 16 Intermittent (3 x 380–440 V) [A] 3.3 4.5 6.2 7.9 11 14.3 17.6 Continuous (3 x 441–480 V) [A] 2.7 3.4 4.8 6.3 8.2 11 14.5
Intermittent (3 x 441–480 V) [A] 3.0 3.7 5.3 6.9 9.0
12.1 15.4
Continuous kVA (400 V AC) [kVA] 2.1 2.8 3.9 5.0 6.9 9.0 11.0
Continuous kVA (460 V AC) [kVA] 2.4 2.7 3.8 5.0 6.5
8.8 11.6
Max. cable size: (line power, motor, brake) [[mm
2
/ AWG]
2)
4/10
Max. input current
Continuous (3 x 380–440 V) [A]
2.7 3.7 5.0 6.5 9.0
11.7 14.4
Intermittent (3 x 380–440 V) [A]
3.0 4.1 5.5 7.2 9.9 12.9 15.8
Continuous (3 x 441–480 V) [A]
2.7 3.1 4.3 5.7 7.4
9.9 13.0
Intermittent (3 x 441–480 V) [A]
3.0 3.4 4.7 6.3 8.1 10.9 14.3
Max. pre-fuses
1)
[A]
10 10 20 20 20
32 32
Environment Estimated power loss at rated max. load [W]
4)
58 62 88 116 124 187 255
Weight enclosure IP20 [kg] 4.8 4.9 4.9 4.9 4.9 6.6 6.6
Weight enclosure IP 21 [kg]
Weight enclosure IP 55 [kg] 13.5 13.5 13.5 13.5 13.5 14.2 14.2
Weight enclosure IP 66 [kg] 13.5 13.5 13.5 13.5 13.5
14.2 14.2
Efficiency
3)
0.96 0.97 0.97 0.97 0.97 0.97 0.97
Table 9.3: Line Power Supply 3 x 380–480 V AC
VLT
®
HVAC Drive Instruction Manual 9 Specifications
MG.11.AB.22 - VLT
®
is a registered Danfoss trademark 9-3
9
