Page 34
3 Press the Enter key to view the total number of cards printed on this printer.
4 Press the Enter key to return to Card Counters. “Cycle Count” appears on line 2.
5 Press the Enter key to view the total number of printhead cycles.
A cycle is one pass of the printhead. With monochrome (K) ribbon, one cycle prints
the front of the card. A second cycle might print the back of the card. With full-color
YMCKT ribbon, each color panel uses one print cycle; the front of the card uses five
print cycles.
6 Press the Enter key to return to Card Counters. “Complete Cards” appear on line
2.
7 Press the Enter key to view the total number of cards printed successfully.
8 Press the Enter key to return to Card Counters. “Rejected Cards” appears on line
2.
9 Press the Enter key to view the total number of cards rejected and placed in the
Reject bin.
