Page 9
Loading laminator supply material
If your printer has locks, unlock and lift the top cover to release the laminator cartridge(s).
1 Remove the laminator cartridge from the printer.
Change the supply in one laminator at a time.
2 Open the gate on the laminator cartridge (1).
3 Remove both used spools (2) from the cartridge (if present).
4 Remove the new supply material from the packaging.
5 Load the new roll of laminator supply material in the cartridge.
— Put the full spool on the supply spindle of the cartridge (A). Push until
the spool clicks onto the spindle.
— Put the empty take-up spool on the spindle with the solid black gear
(B). Push until the spool clicks onto the spindle.
— Turn the take-up spool to remove slack from the material.
2
2
1
A
B
