Page 2
On the left and back sides of the printer:
Printer Guide Holder: Attach the holder and place the
guide in it. Choose any convenient location.
Ethernet Data Port:. Use only one data port.
USB Data Port: Use only one data port.
Manual Advance Knob: Use to move a card in the printer
or to turn rollers.
Cable Guide: Place the data cable in the guide.
Back Door. Open to see both duplex units and the reject
bin.
Locks: Optional lock secures cards and supplies in the
printer. See "Features and options" on page 3.
Optional Smart Card USB Port: See "Features and
options" on page 3.
Optional Smart Card Serial Port: See "Features and
options" on page 3.
Power Switch: Press the switch to power on the printer.
Power Receptacle: Plug in the power cord.
Security Lock Receptacle: Connect the optional
security lock to the opening.
