Chapter 24. Fan Board
Figure 24-2. DM4008 FAN board without blank panels
24.2. Air Flow
The next figures show how the air flows inside DM4004 and DM4008 Chassis.
24.2.1. DM4004 and DM4008 Chassis
Figure 24-3. Air flow inside DM4004 19"
89
