Chapter 13. DM4000 ETH12GX+1x10GX
CAUTION:
"Risk of explosion if battery is replaced by an incorrect type. Use only cell type CR2032. Dispose of used
batteries according with local regulations."
13.2. Front Panel Description
DM4000 ETH12GX+1x10GX front panel contains 12 SFP ports, 1 XFP port and port status LEDs.
Figure 13-2. DM4000 ETH12GX+1x10GX - Front Panel
WARNING:
"When performing installation and maintenance operations of optical fibers, you should not stand close
or look directly into the fiber outlet with unaided eyes."
WARNING:
"Electrostatic generated by human body may damage the electrostatic sensitive components on the equip-
ment."
WARNING:
"This interface board supports a 3.15A fuse, type T (delay), 250V. If necessary, replace it only for another
one of the same type and value"
51
