Datacom DM4000 Series User Manual

Chapter 7. DM4000 MPU192
CAUTION:
"Risk of explosion if battery is replaced by an incorrect type. Use only cell type CR2032. Dispose of used
batteries according with local regulations."
7.2. Front Panel Description
The DM4000 MPU192 Front Panel has system status LEDs, one Ethernet Outband Management port
(MGMT ETH), one RS-232 Serial port (Console) and one Auxiliar port (AUX).
Figure 7-2. DM4000 MPU192 - Front Panel
WARNING:
"Electrostatic generated by human body may damage the electrostatic sensitive components on the equip-
ment."
WARNING:
"The interface board supports a 3.15 fuse, type T (delay), 250V. If necessary, replace it only for another
one of the same type and value."
27
