Chapter 14. DM4000 ETH2x10GX

14.4.2. Hardware

Table 14-2. Hardware DM4000 ETH2x10GX

Feature Description

Switch L2 Wire Speed

Router 3 Wire Speed

QoS L2-L4

MPLS LDP/RSVP/L2VPN

PoE N/A

Ports 2 x 10G (XFP)

Packet Buffer 128MB

Switch Fabric (intern) 40 Gbps

Flash 64MB

SDRAM 256MB

MAC address table 1024k*

L3 hosts (IPv4) 32k*

L3 hosts (IPv6) 16k*

L3 Routes (IPv4) 240k*

L3 Routes (IPv6) 240k*

L2 Multicast groups 1k

L3 Multicast groups (Ipv4) 4k

L3 Multicast groups (IPv6) 1k

Filters 4k

Meters 4k

Counters 4k

Important: *maximum value - Actual values vary lower due to resource sharing
